| Wood Clad Sun Room Overall Length - Flashing to Flashing | |||
| No. of Bays in Length |
0 Gable Ends |
1 Gable End |
2 Gable Ends |
| 3 | 8' - 1 3/4" | 8' - 3 1/2" | 8' - 5 1/4" |
| 4 | 10' - 9 1/4" | 10' - 11" | 11' - 0 3/4" |
| 5 | 13' - 4 3/4" | 13' - 6 1/2" | 13' - 8 1/4" |
| 6 | 16' - 0 1/4" | 16' - 2" | 16' - 3 3/4" |
| 7 | 18' - 7 3/4" | 18' - 9 1/2" | 18' - 11 1/4" |
| 8 | 21' - 3 1/4" | 21' - 5" | 21' - 6 3/4" |
| 9 | 23' - 10 3/4" | 24' - 0 1/2" | 24' - 2 1/4" |
| 10 | 26' - 6 1/4" | 26' - 8" | 26' - 9 3/4" |
| 11 | 29' - 1 3/4" | 29' - 3 1/2" | 29' - 5 1/4" |
| 12 | 31' - 9 1/4" | 31' - 11" | 32' - 0 3/4" |
| 13 | 34' - 4 3/4" | 34' - 6 1/2" | 34' - 8 1/4" |
| 14 | 37' - 0 1/4" | 37' - 2" | 37' - 3 3/4" |
| 15 | 39' - 7 3/4" | 39' - 9 1/2" | 39' - 11 1/4" |
| 16 | 42' - 3 1/4" | 42' - 5" | 42' - 6 3/4" |
| 17 | 44' - 10 3/4" | 45' - 0 1/2" | 45' - 2 1/4" |
| 18 | 47' - 6 1/4" | 47' - 8" | 47' - 9 3/4" |
| 19 | 50' - 1 3/4" | 50' - 3 1/2" | 50' - 5 1/4" |
| 20 | 52' - 9 1/4" | 52' - 11" | 53' - 0 3/4" |
| 21 | 55' - 4 3/4" | 55' - 6 1/2" | 55' - 8 1/4" |
| 22 | 58' - 0 1/4" | 58' - 2" | 58' - 3 3/4" |
| 23 | 60' - 7 3/4" | 60' - 9 1/2" | 60' - 11 1/4" |
| 24 | 63' - 3 1/4" | 63' - 5" | 63' - 6 3/4" |
| 25 | 65' - 10 3/4" | 66' - 0 1/2" | 66' - 2 1/4" |
| 26 | 68' - 6 1/4" | 68' - 8" | 68' - 9 3/4" |
| 27 | 71' - 1 3/4" | 71' - 3 1/2" | 71' - 5 1/4" |
| 28 | 73' - 9 1/4" | 73' - 11" | 74' - 0 3/4" |
| 29 | 76' - 4 3/4" | 76' - 6 1/2" | 76' - 8 1/4" |
| 30 | 79' - 0 1/4" | 79' - 2" | 79' - 3 3/4" |
| 31 | 81' - 7 3/4" | 81' - 9 1/2" | 81' - 11 1/4" |
| 32 | 84' - 3 1/4" | 84' - 5" | 84' - 6 3/4" |
| 33 | 86' - 10 3/4" | 87' - 0 1/2" | 87' - 2 1/4" |
| 34 | 89' - 6 1/4" | 89' - 8" | 89' - 9 3/4" |
| 35 | 92' - 1 3/4" | 92' - 3 1/2" | 92' - 5 1/4" |
| 36 | 94' - 9 1/4" | 94' - 11" | 95' - 0 3/4" |
| 37 | 97' - 4 3/4" | 97' - 6 1/2" | 97' - 8 1/4" |
| 38 | 100' - 0 1/4" | 100' - 2" | 100' - 3 3/4" |
| 39 | 102' - 7 3/4" | 102' - 9 1/2" | 102' - 11 1/4" |
| 40 | 105' - 3 1/4" | 105' - 5" | 105' - 6 3/4" |
